〖System introduction〗

（1）The system belongs to the vertical system of plywood formwork without frame timber beam.

（2）It is composed of 18mm thick multi-layer panel, H20 (200mm * 80mm) timber beam, back ridge, timber beam connecting claw, cantilever, diagonal brace, external angle pull device, right angle core belt, straight core belt, through wall bolt, PVC sleeve, casing plug, hook, steel pin and other accessories.

（3）The system is widely used in various kinds of projects, such as construction, water conservancy and hydropower, bridges and culverts, high-rise structures, etc.

                         〖System characteristics〗

（1）With large formwork area, few joints and strong applicability, it can be flexibly assembled into various forms of formwork structure, especially the structure with complex shape, which provides a wide space for architectural design.。

（2）It has large rigidity, light weight and strong bearing capacity, which greatly reduces the support and expands the floor construction space.

（3）Easy to assemble and disassemble, flexible to use, easy to assemble and disassemble on site, greatly improving the construction speed.

（4）All connectors are highly standardized and versatile.

（5）Low cost, high times of reuse, thus reducing the overall cost of the project.
